Product Introduction
| Part Number | d(mm) | D(mm) | B1 (mm) | r1 min (mm) | Cr (KN) | C0r (KN) |
Speed limit Grease (rpm) |
Speed limit Oil (rpm) |
Mass (kg) |
| 2304J | 20 | 52 | 21 | 1,1 | 18 | 4,65 | 13000 | 16000 | 0,226 |
| 2305TV | 25 | 62 | 24 | 1,1 | 24,5 | 6,55 | 10000 | 13000 | 0,335 |
| 2306TV | 30 | 72 | 27 | 1,1 | 31,5 | 8,65 | 8500 | 10000 | 0,552 |
| 2307TV | 35 | 80 | 31 | 1,5 | 39 | 11,2 | 7500 | 9000 | 0,743 |
| 2308TV | 40 | 90 | 33 | 1,5 | 45 | 13,4 | 6700 | 8000 | 1 |
| 2309TV | 45 | 100 | 36 | 1,5 | 54 | 16,3 | 6000 | 7000 | 1,32 |
| 2310TV | 50 | 110 | 40 | 2 | 64 | 20 | 5300 | 6300 | 1,78 |
| 2311TV | 55 | 120 | 43 | 2 | 75 | 23,6 | 4800 | 5600 | 2,29 |
| 2312TV | 60 | 130 | 46 | 2,1 | 86,5 | 28 | 4300 | 5000 | 2,83 |
| 2313TV | 65 | 140 | 48 | 2,1 | 95 | 32,5 | 4000 | 4800 | 3,43 |
| 2314M | 70 | 150 | 51 | 2,1 | 110 | 37,5 | 3600 | 4300 | 4 |
| 2315M | 75 | 160 | 55 | 2,1 | 122 | 42,5 | 3400 | 4000 | 5,2 |
| 2316M | 80 | 170 | 58 | 2,1 | 137 | 48 | 3200 | 3800 | 6,44 |
| 2317M | 85 | 180 | 60 | 3 | 140 | 51 | 3000 | 3600 | 7,47 |
| 2318M | 90 | 190 | 64 | 3 | 153 | 57 | 2800 | 3400 | 8,82 |
| 2319M | 95 | 200 | 67 | 3 | 163 | 64 | 2600 | 3200 | 10,3 |
| 2320M | 100 | 215 | 73 | 3 | 193 | 78 | 2400 | 3000 | 12,9 |
